Adjustment Rod
Calibration
Tube
LVDT
“O” Rings
Enlarged Detail
of
Adjustment Rod
Enclosing Tube
P.C. Board
C-ring Located
Here on Process
Level Sensors
White Teflon Spacer
Must Be Installed
Base and Junction Box
Stand
S
P
.2
.4
.6
.8
1.0
.2
.4
.6
.
8
1.0
LVDT Core

13
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
%
Figure 16
Digital Meter Removal
Note: For units with meter, pull meter
out to access wiring terminals
Figure 15
Bench Calibration Stand
(part number 31-6107-001)
