Magnetrol ES Modulevel - Parts; Replacement P.C. Boards

35
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
E-tube kit
Standard High Temperature
CS to 600# 89-5944-001 89-5944-004
SS to 600# 89-5944-002 89-5944-007
CS - 900# 89-5944-002 89-5944-003
CS 1500# & up 89-5944-005 89-5944-006
E-tube Gasket
A
ll Pressures 12-1204-001
Spring Assembly
0.5 SG 1.0 SG 2.0 SG Hi Press 1.0 SG
CS Low Temp 32-8129-003 32-8129-001 32-8129-005 32-8120-002
SS Low Temp 32-8129-004 32-8129-002 32-8129-006 n/a
CS/SS Hi Temp 32-8129-008 32-8129-007 32-8129-009 32-8120-002
Stem Assembly
Pressure E-tube 0.5 SG 1.0 SG 2.0 SG
600# or less standard 32-5841-003 32-5841-004 32-5841-004
600# or less High Temp 32-5841-005 32-5841-006 32-5841-006
4" 900# standard n/a 32-5855-001 n/a
4" 900# High Temp n/a 32-5855-006 n/a
6" 900# standard n/a 32-5855-002 n/a
6" 900# High Temp n/a 32-5855-007 n/a
4" 1500# standard n/a 32-5855-002 n/a
4" 1500# High Temp n/a 32-5855-007 n/a
6" 1500# standard n/a 32-5855-004 n/a
6" 1500# High Temp n/a 32-5855-009 n/a
4" 2500# standard n/a 32-5855-003 n/a
4" 2500# High Temp n/a 32-5855-008 n/a
6" 2500# standard n/a 32-5855-005 n/a
6" 2500# High Temp n/a 32-5855-010 n/a
Flange/Flange Assembly
150# 300# 600# 900# 1500# 2500#
3" CS 0.5 89-4217-001 89-4219-001 89-4221-001 n/a n/a n/a
3" CS 1.0/2.0 89-4218-001 89-4220-001 89-4222-001 n/a n/a n/a
4" CS 0.5 Z31-4804-007 Z31-4804-008 Z31-4804-009 n/a n/a n/a
4" CS 1.0/2.0 Z31-4804-010 Z31-4804-011 Z31-4804-012 Z04-8606-001 Z04-8606-002 Z04-8606-003
6" CS 0.5 Z31-4804-013 Z31-4804-014 Z31-4804-015 n/a n/a n/a
6" CS 1.0/2.0 Z31-4804-016 Z31-4804-017 Z31-4804-018 Z04-8606-004 Z04-8606-005 Z04-8606-006
3" SS 0.5 89-4238-001 89-4238-003 89-4238-005 n/a n/a n/a
3" SS 1.0/2.0 89-4238-002 89-4238-004 89-4238-006 n/a n/a n/a
4" SS 0.5 Z31-4806-007 Z31-4806-008 Z31-4806-009 n/a n/a n/a
4" SS 1.0/2.0 Z31-4806-010 Z31-4806-011 Z31-4806-012 n/a n/a n/a
6" SS 0.5 Z31-4806-013 Z31-4806-014 Z31-4806-015 n/a n/a n/a
6" SS 1.0/2.0 Z31-4806-016 Z31-4806-017 Z31-4806-018 n/a n/a n/a
Head Flange- Gasket Only (not pictured)
150# 300# 600# 900# 1500# 2500#
3" 12-1301-17 12-1301-018 12-1204-021 n/a n/a n/a
4" n/a n/a n/a 12-1204-009 12-1204-010 12-1204-011
4.7.4 Mechanical Replacement Parts
7
8
9
10
11
