48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
1 4 mA
apply new 4 mA input
2 20 mA
apply new 20 mA input
3 20 mA by %
enter % of span vs.
actual level
4 End
1 Set Dry Point
for use when SG will be changed,
dry point set with displacer hanging free
completely out of liquid.
2 LVDT %
read out %
3 Spec Grav
set SG value
4 Error Codes
if value other than 0000, consult factory
5 New password
enter new password, or enter value “0”
to disable password function
6 Trim 4 mA Point
factory set
7 Trim 20 mA Point
factory set
8 4 mA Trim Point
factory set
9 20 mA Trim Point
factory set
10 Set Serial Number
factory set
1 Model
2 Manufacturer
3 Set Magnetrol S/N
4 Dev id
5 Tag
6 Descriptor
7 Message
8 Damping
9 Fault State
10 Date
11 Final Assembly
12 Universal rev
13 Fld dev rev
14 Software rev
15 Poll addr
16 Number req preams
1 4 mA
unit blocks at 4 mA
2 20 mA
unit blocks at 20 mA
3 Other
enter a value between 3.6 and 22 mA
4 End
1
Set as 4 mA value
current level will be new 4 mA level
2 Read new value
introduce a value that will match 4 mA
3
Leave as found
keep old 4 mA level
1 Set as 20 mA value
current level will be new 20 mA level
2 Read new value
Introduce a value that will match 20 mA
3 Leave as found
keep old 20 mA value
