48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
4.6.2 CSA (Canadian Standards Association)
Model Approval
XE5X-XXXX EZA, B, C, E, F, G, L, N Explosion Proof
with transmitter codes:
E
SA, E, F, G, 7, 9 Class I, Div. 1; Groups B, C, D
GZH, K, Q, R, S, T, U, V, 2, 3, 5, 6 Class II, Div. 1; Groups E, F, G
GSH, K, Q, T, 4, 7 Class III, Type 4X
RZW, X
RSW, X, 4
E5X-XXXX EZD, H, I, K Intrinsically Safe
with transmitter codes:
ESD, H, I, J, K, 8 Class I, Div. 1; Groups A, B, C, D
GZH, K, Q, T  Class II, Div. 1; Groups E, F, G
GSH, K, Q, T, 4, 7  Class III, Type 4X
RZQ, T Entity
RSQ, T, Z
E5X-XXXX EZD, H, I, K Non-Incendive
with transmitter codes:
ESD, H, I, J, K, 8 suitable for:
GZH, K, Q, T  Class I, Div. 2; Groups A, B, C, D
GSH, K, Q, T, 4, 7  Class II, Div. 2; Groups E, F, G
RZQ, T Class III, Type 4X
RSQ, T, Z
4.6.3 ATEX (European Directive for Explosion Protection
Model Approval
ATEX XEXX-XXXX, EXX-XXXX with transmitter codes Explosion Proof

EZA, E, F, G ATEX Ex II 1/2 G EEx d IIC T6
ESA, E, F, G, 7, 9
RZW, X
RSW, X, 4
EXX-XXXX with transmitter codes Intrinsically Safe

ESD, I, H, K ATEX Ex II 1 G EEx ia IIC T6
RSQ, T
EXX-XXXX with transmitter codes Intrinsically Safe

ESJ, 8 ATEX Ex II 1 G EEx ia IIC T5
RSZ
These units have been tested to EN 50081-2
and EN 50082-2 and are in compliance with
the EMC Directive 89/336/EEC.
 Field wiring must be installed in conduit.
 If IS or NI CSA nameplate is required, this must be specified at time
of order placement.
 ATEX EP approval available on standard 900#, 1500#, and 2500#
models. 150#, 300#, and #600 models require modification for ATEX
EP approval and must be “X’d” for a heavy wall e-tube.
 Entity parameters for ATEX EEx ia installation:
Ci = 5 nF, Li = 800 µH
Ui = 28.4 V, Pi = 0.67 W or
Ui = 26.4 V, Li = 99 mA, Pi = 0.66 W
