Magnetrol ES Modulevel - Parts; Replacement PC Boards

33
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
Serial Number Format (6 digits)-(2 digits)-(3 digits) 6 or 7 digits
Analog EZ Date of Manufacture 1996 - present 1984 - 1997
P.C. Board Description
Six pin potentiometer Ten pin potentiometer
connector connector
Supply Transmitter Transmitter
New EZ board Original EZ board
Voltage Mounting Code
24 VDC
Integral
EZA/EZG/EZE/EZF 89-7826-004 89-7826-001
24 VDC EZD/EZI/EZH 89-7826-004 89-7826-001 
120 VAC EZB/EZL 89-7826-005 89-7826-002
240 VAC EZC/EZN 89-7826-006 89-7826-003
24 VDC EZ1/EZ4/GZH/GZK 89-7826-004 89-7826-001
120 VAC EZ2/EZ5/GZ2/GZ5 89-7826-005 30-2163-002
240 VAC EZ3/EZ6/GZ3/GZ6 89-7826-006 89-7826-003
24 VDC
Remote
EZQ/EZT/GZQ/GZT/GZZ 89-7826-004 89-7826-001
120 VAC EZR/EZU/GZR/GZU 89-7826-005 89-7826-002
240 VAC EZS/EZV/GZS/GZV 89-7826-006 89-7826-003
24 VDC HT-Integral RZW/RZX/RZQ/RZT 89-7826-004 n/a
4.7 Parts
4.7.1 Replacement P.C. Boards
S
erial Number Format (6 digits)-(2 digits)-(3 digits) 6 or 7 digits
Digital ES Date of Manufacture 1998 - present 1995 - 1999
P.C. Board Description Potted module Through hole
Supply Transmitter Transmitter
ES II board ES I board
Voltage Mounting Code
Integral
ESA/ESD/ESG/ESI/ESE/ESH/ESF
ESJ/ES9/ESK/ES7/ES8
ES1/ES4/GSH/GSK
24 VDC
Remote
GS7
89-9113-001

ESQ/EST/GSQ/GST
GS4
HT-Integral RSQ/RSW/RST/RSX/RS4/RSZ
Replacement Electronic Modulevel Boards
 All digital ES boards are to be replaced with ES II transmitter boards as indicated.
 CENELEC IS units require complete transmitter head replacement if PC board or LVDT is required.
