Chamber
M
aterials Carbon steel
316/316L stainless steel
Wetted parts 304/304L and 316/316L (900# and
greater) and Inconel (spring)
316/316L (600# and less) and Inconel
(spring)
Process connections Tank Top: 3", 4", 6" ANSI Flange
Chambered: 1
1
⁄2", 2" NPT
1
1
⁄2", 2" Socketweld
1
1
⁄2", 2" ANSI Flanges
Process Conditions
Process temperature range * Steam applications:
-20° F to +500° F (+260° C)
Non-steam applications:
-20° F to +600° F (-29°C to +315° C)
Process pressure range 4265 psig @ +100° F
(294 bar @ +38° C)
Environmental
Electronics -40° F to +160° F (-40° C to +70° C)
operating temperature
Display function -4° F to +160° F (-20° C to +70° C)
operating temperature
Storage temperature -40° F to +185° F (-40° C to +85° C)
Electromagnetic Meets CE Requirements
compatibility (EN 50081-2, EN 50082-2)
4.8.2 Performance
Linearity (independent) LVDT: +/- 0.25% of full span
Mechanical/electrical: +/- 0.25%
of full span
Repeatability +/-0.20% of full span
Resolution 0.05 % of range ± 1 digit
Ambient temperature Maximum zero shift
effect is 0.031% of effect/°F
Operating Temp. range: -40° to +160° F (-40° to +70° C)
Digital Meter Temp. Range: -4° to +160° F (-20° to +70° C)
Storage Temp. Range: -40° to +185° F (-40° to +85° C)
Electromagnetic Compatibility: Meets CE Requirements
(EN 50081-2, EN 50082-2)
* Maximum process temperatures are based on ambient
temperatures less than or equal to +120° F (+49° C). Higher
ambient temperatures require reduced process temperatures.
40
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
