Magnetrol ES Modulevel - Physical

42
48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
Figure 32
E51 Series with Integral Top Mounting
900, 1500, 2500 lb. Class
Level
range
Dia.
A
NSI standard flange
C
10.75
(273)
8.62
(219)
1" NPT
conduit
connector
B
Figure 33
E55 Series with Side/Side Connections, Remote Mount
900, 1500, 2500 lb. Class
10.75
(273)
1" NPT
5.00
(127)
3.00
(76)
2.00 (51)
3.50 (89)
2.75 (70)
Remote Mount
Bracket
1
/2"
NPT
1" NPT
conduit
connector
Up to 75' (23 m)
of Connecting
Cable, part
number
037-3218-0XX
or
037-3220-0XX,
run in conduit.
Cable must be
ordered separately.
1" NPT
drain
Level
range
(2) 1
1
/2" or 2"
NPT or
socket weld
(2)  1
1
/2" or 2"
ANSI standard
flange
(Refer to chart for
class and size.)
F
J
G
L
N
Mid
Range
8.62
(219)
Figure 34
E53 Series with Upper Side/Bottom Connections, Integral Mount
900, 1500, 2500 lb. Class
10.75
(273)
8.62
(219)
1" NPT
conduit
connector
B
Level
range
(2) 1
1
/2" or 2" ANSI
standard flange
(Refer to chart for
class and size.)
Mid
Range
(2) 1
1
/2" or 2" NPT
or socket weld
G
M
H
L
F
K
E
Outlet Size
Dimensions
LM
1
1
⁄2" NPT or Socket Weld
4.00 3.44
(102) (87)
2" NPT or Socket Weld
4.38 3.50
(111) (89)
Flange Size
Dimensions
& Class
BCE FGH JK N
1
1
⁄2" – 900 lb.
7.25 8.43
16.38 9.31 25.81 9.31
(184) (214)
3.44 11.50 20.57
(416) (236) (655) (236)
8.18 9.38
(87) (292) (522)
2" – 900 lb.
(208) (238)
1
1
⁄
2
" – 1500 lb .
7.93 9.13
16.75 9.31 26.19 9.31
(201) (232)
3.44 12.25 20.94
(425) (236) (665) (236)
8.87 10.13
(87) (311) (532)
2" – 1500 lb.
(225) (257)
1
1
⁄2" – 2500 lb.
9.06 10.25
17.62 9.31 27.06 9.31
(230) (267)
3.44 14.00 21.81
(447) (236) (687) (236)
9.87 11.13
(87) (356) (554)
2" – 2500 lb.
(251) (283)
D
imensional specifications for high pressure models E51, E53, E55
