48-618 ES/EZ Modulevel Displacer Level Transmitter (Top Hat Assembly Design)
TRANSMITTER TYPE & MOUNTING
E Electronic Integral Mount
G Electronic Remote Mount
R Electronic High-temp Integral Mount
TRANSMITTER OUTPUT
Z 4-20 mA only (Analog) 24 VDC, 120 VAC or 240 VAC
S 4-20 mA with HART (Digital)
24 VDC only
TRANSMITTER CONFIGURATION AND ACCESSORIES
Code Display Input Voltage Agency Approval
A None 24 VDC EP – FM, CSA, CENELEC
B None 120 VAC EP – FM, CSA
Integral Mount
C None 240 VAC EP – FM, CSA
D None 24 VDC IS/NI – FM, CSA, CENELEC
Fourth Digits
G Analog 24 VDC EP – FM, CSA, CENELEC
1, 2, 3 only
I Analog 24 VDC IS/NI – FM, CSA, CENELEC
Eighth Digit E only L Analog 120 VAC EP – FM, CSA
N Analog 240 VAC EP – FM, CSA
+300° F max.
J Digital 24 VDC IS/NI – FM, CSA
9 Digital 24 VDC EP – FM, CSA, CENELEC
H None 24 VDC EP – FM, CSA
Remote Mount
2 None 120 VAC EP – FM, CSA
Fourth Digits
3 None 240 VAC EP – FM, CSA
7, 8, 9 only
K Analog 24 VDC EP – FM, CSA
Eighth Digit G only
5 Analog 120 VAC EP – FM, CSA
+400° F max.
6 Analog 240 VAC EP – FM, CSA
7 Digital 24 VDC EP – FM, CSA
Q None 24 VDC IS/NI – FM, CSA, CENELEC
HT-Integral Mount
W None 24 VDC EP – FM, CSA, CENELEC
Fourth Digits
T Analog 24 VDC IS/NI – FM, CSA, CENELEC
7 ,8, 9 only
X Analog 24 VDC EP – FM, CSA, CENELEC
Eighth Digit R only
4 Digital 24 VDC EP – FM, CSA, CENELEC
+500° F max.
Z Digital 24 VDC IS/NI – FM, CSA
Q None 24 VDC EP – FM, CSA
Remote Mount
R None 120 VAC EP – FM, CSA
Fourth Digits
S None 240 VAC EP – FM, CSA
7, 8, 9 only
T Analog 24 VDC EP – FM, CSA
Eighth Digit G only
U Analog 120 VAC EP – FM, CSA
+500° F max.
V Analog 240 VAC EP – FM, CSA
4 Digital 24 VDC EP – FM, CSA
Last 3 Digits of Model Number
HART communicator sold separately
REMOTE CONNECTING CABLE
Up to +400° F, specify cable 037-3218-0XX, where last two digits are
cable length in feet from 1-75 feet.
Up to +500° F, specify cable 037-3220-0XX, where last two digits are
cable length in feet from 1-75 feet.
120 & 240 VAC available on Analog unit only (ninth digit Z)
Digital meter available on Digital Hart compatible unit only (ninth digit S)
