47-602 F10 and F50 Flow Switches
15
To determine the actuating flow rates for liquids other than
water (approximate viscosity of 20 centistokes or less), a
specific gravity correction factor must be applied to the
water flow rates given in the table.
Example: The maximum adjustment for an increasing flow
rate with a liquid specific gravity of .70 in an 8"
line is: 230 GPM x 1.20 = 276 GPM.
.40 1.58 .95 1.03
.45 1.49 1.00 1.00
.50 1.41 1.05 .98
.55 1.35 1.10 .95
.60 1.29 1.15 .93
.65 1.24 1.20 .91
.70 1.20 1.25 .89
.75 1.15 1.30 .88
.80 1.12 1.35 .86
.85 1.08 1.40 .85
.90 1.05 1.45 .83
4.3 Specific Gravity
