24
47-602 F10 and F50 Flow Switches
Housing cover See Switch and housing reference on previous page
Housing base See Switch and housing reference on previous page
Switch mechanism See Switch and housing reference on previous page
Switch See Switch and housing reference on previous page
Enclosing tube Z32-6325-002
Enclosing tube gasket 012-1204-001
O-ring Not required 012-1204-036
Body adaptor Not required 004-0481-001
Threaded body 002-5703-003 002-5703-004 002-5705-003 002-5705-004
Flow piston stop 005-5420-121 Not required
Flow piston assembly 032-7127-001 032-7127-003 032-7127-002
Lock nut
➀
010-2107-002 010-2107-003
Flow disc
➁
Specify model number and serial number
4.5.2.4 Model F50 Stainless Steel Body Replacement Parts
Housing cover See Switch and housing reference on previous page
Housing base See Switch and housing reference on previous page
Switch mechanism See Switch and housing reference on previous page
Switch See Switch and housing reference on previous page
Enclosing tube Z32-6325-002
Enclosing tube gasket 012-1204-001
O-ring Not required 012-1204-036
Body adaptor Not required 004-0481-001
Threaded body 002-5703-001 002-5703-002 002-5705-001 002-5705-002
Flow piston stop 005-5420-121 Not required
Flow piston assembly 032-7108-001 032-7109-001 032-7109-002
Lock nut
➀
010-2107-002 010-2107-003
Flow disc
➁
Specify model number and serial number
➀ Use insoluble adhesive on nut when attaching new flow disc.
➁ When actuation flow rate is critical, the entire control be returned to
the factory for replacement and recalibration of flow disc.
4
.5.2.3 Model F50 Bronze Body Replacement Parts
