47-602 F10 and F50 Flow Switches
17
Model F10 units may be adjusted in service to actuate within the
m
inimum and maximum flow rates given below. A specific
gravity correction factor is applied for liquids other than water
(1.00 specific gravity).
➀
➁
2 4.8 14.3 3.6 10.9
2
1
⁄2 5.2 16.8 4.5 12.7
3 7.3 20.0 5.4 14.8
3
1
⁄2 8.6 22.7 6.4 17.0
4 10.2 27.2 7.5 19.3
5 13.8 34.1 9.8 25.0
6 17.9 40.9 12.5 29.5
8 27.2 52.2 18.6 36.3
10 38.6 70.4 25.0 47.7
12 52.2 86.3 34.1 56.8
14 61.3 97.6 38.6 63.6
16 77.2 115.8 49.9 72.6
18 97.6 133.8 61.3 84.0
20 118.0 156.6 72.6 97.6
22 140.7 177.1 86.3 109.0
24 165.7 204.3 102.2 124.9
26 193.0 233.8 118.0 140.7
28 222.5 263.3 133.9 158.9
30 252.0 292.8 152.1 177.1
4.4 Specifications
➀ Based upon Sch 40 pipe.
➁ For higher flow rates consult factory.
