Magnum MS2012 - Figure 2-5, MS Dimensions (MS2000)

© 2016 Sensata TechnologiesPage 13
Installation
Figure 2-5, MS Dimensions (MS2000)
12 ⅝"
(32.1 cm)
12"
(30.5 cm)
2"
(5.1 cm)
4 ⅞"
(12.4 cm)
4 ⅞"
(12.4 cm)
6 ⅝"
(16.8 cm)
30
13 ¾"
(34.9 cm)
Mounting Holes
Keyhole
slots (x4)
Mounting
Holes (x4)
Use up to
9/32"
(7 mm)
screw/bolt
6 ⅝"
(16.8 cm)
Bottom
Left
Side
Right
Side
Front
Exhaust Air Vents
Air Intake
Vents
Air Intake Vents
Top
