2.5.6 AC Wiring Confi gurations (MS2012, MS2812, MS2024, MS4024, & MS4048)
The following table provides the different wiring confi gurations for installing and connecting the AC
conductors to and from the inverter (refer to Figures 2-11 to 2-15 for installation drawings showing
these confi gurations). Refer to Table 2-4 (and Figures 2-16 & 2-17) for the MS2000 models.
Table 2-3, AC Input/Output Wiring Confi gurations
SI/SO (30A)
Single In/
Single Out
SI/SO (60A)
Single In/
Single Out
SI/DO
Single In/
Dual Out
DI/SO
Dual In/
Single Out
DI/DO
Dual In/
Dual Out
AC Source
1
Required
120 VAC
@≤30A
120 VAC
@>30A (60A)
120/240 VAC (or
2 separate legs of
120 VAC)
@≤15A per leg
(-15B models);
or ≤20A per leg
(-20B models)
120/240 VAC
(or 2 separate
legs of 120
VAC)
@≤30A per leg
120/240 VAC (or
2 separate legs
of 120 VAC)
@≤30A per leg
Reason to
Use
Have an 120
VAC source that
is ≤30A.
Requires
a separate
inverter
sub-panel.
Have an 120
VAC source
that is >30A.
Requires
a separate
inverter
sub-panel.
A separate
inverter sub-
panel is not
required for -XXB
models.
Inverter pass-
thru capability
limited on each
leg by model
used.
Want dedicated
charging and
dedicated
pass-thru while
the AC source
is on.
Requires
a separate
inverter sub-
panel.
May need to
power 240
VAC loads
if AC source
on (requires
120/240 VAC
source).
Requires a
separate inverter
sub-panel.
Appropiate
Models
MS2012
MS2812
MS2024
MS4024
MS4048
MS2012
MS2812
MS2024
MS4024
MS4048
MS2012-20B
MS2012-15B
MS2812
3
MS2024
3
MS4024
3
MS4048
3
MS4048-20B
MS2012
MS2812
MS2024
MS4024
MS4048
MS2012
MS2812
MS2024
MS4024
MS4048
Maximum
Input
Breaker
Required
–
Minimum
Wire Size
(AWG)
30A
(single pole)
–
#10 AWG
(In & Out)
60A
(single pole)
–
#6 AWG
(In & Out);
Can be split to
two #10 AWG
(for HOT 1
& HOT 2)
For full charging
and pass-thru
-15B=45A SP
-20B=60A SP
–
-15B In=#8
(split to #12 x2)
-20B In=#6
(split to #10 x2)
-15B Out=#14 x2
-20B Out=#12 x2
30A
(dual pole)
–
#10 AWG
(In & Out)
30A
(dual pole)
–
#10 AWG
(In & Out)
Maximum
Inverter
Pass-thru
capacity
3600W
(30A @120
VAC)
7200W
(60A @120
VAC)
-15B models:
15A/leg
(30A max.);
-20B models:
20A/leg
(40A max.)
3600W
(30A @120
VAC)
7200W
(2 legs of 30A
@120/240 VAC
or 2 legs of 30A
@120 VAC)
2
Diagram
Figure 2-11 Figure 2-12 Figure 2-13 Figure 2-14 Figure 2-15
Note
1
– AC source is from either the utility/grid power (i.e., shorepower) or an AC generator.
Note
2
– If two legs of 30A @120 VAC used, they must be from the same source (i.e., common
neutral). For example, 2 legs from a 3-phase source can be used.
Note
3
– These MS Series models require a sub-panel for this particular confi guration.
