Magnum MS2012 - Figure B-4, Battery Bank Wiring Examples (12-Volt)

© 2016 Sensata Technologies
Page 65
Appendix B – Battery Information
Figure B-4, Battery Bank Wiring Examples (12-volt)
12 VDC
battery
(100 AH)
12 VDC
battery
(100 AH)
Series String
(6 VDC + 6 VDC)
6 VDC
battery
(200 AH)
6 VDC
battery
(200 AH)
String
(12 VDC @ 100 AH)
12 VDC
battery
(100 AH)
overcurrent
protection
overcurrent
protection
Series String
(6 VDC + 6 VDC)
6 VDC
battery
(200 AH)
6 VDC
battery
(200 AH)
Series String
(6 VDC + 6 VDC)
6 VDC
battery
(200 AH)
6 VDC
battery
(200 AH)
overcurrent
protection
Parallel String (200 AH + 200 AH)
Parallel String
(100 AH + 100 AH)
overcurrent
protection
12-volt battery bank (parallel two 12-volt batteries)
12-volt battery bank (one string of two 6-volt batteries wired in series)
12-volt battery bank (one string of one 12-volt battery)
to 12 VDC inverter
(total capacity = 200 AH)
to 12 VDC inverter
(total capacity = 200 AH)
to 12 VDC inverter
(total capacity = 100 AH)
to 12 VDC inverter
(total capacity = 400 AH)
12-volt battery bank (two strings of two 6-volt batteries wired in series and connected in parallel)
