Magnum MS2012 - Figure 2-15, AC Wiring for Dual in - Dual out Confi Gurations

Page 30 © 2016 Sensata Technologies
Installation
Figure 2-15, AC Wiring for Dual In – Dual Out Confi gurations
240
VAC only
in standby
Main Panel
(Utility/Generator Input)
MS Series Inverter
AC Terminal Block
(AC input and output wiring)
DUAL IN / DUAL OUT wiring
AC HOT 1 IN
(from main p anel)
AC HOT 1 OUT
(to sub-panel)
AC NEUT IN
(from main p anel)
AC NEUT OUT
(to sub-panel)
AC HOT 2 IN
(from main p anel)
AC HOT 2 OUT
(to sub-panel)
Sub-Panel and Outlets
(Inverter Loads)
120
VAC
120
VAC
AC GROUNDS
(to/from
both panels)
ON
OFF
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OF F
30
..Maximum..
30-amp breaker
(double pole)
required to
inverter AC input
30
In mobile installations: neutral is typically not
connected to ground in main panel.
ON
OF F
ON
OF F
ON
OF F
ON
OF F
ON
OFF
