Magnum MS2012 - Figure B-6, Battery Bank Wiring Examples (48-Volt)

© 2016 Sensata Technologies
Page 67
Appendix B – Battery Information
Figure B-6, Battery Bank Wiring Examples (48-volt)
48-volt battery bank (one string of eight 6-volt batteries wired in series)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
overcurrent protection
to 48 VDC
inverter
(total capacity
= 200 Ahrs)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
12-volt
battery
(100 AH)
12-volt
battery
(100 AH)
48-volt battery bank (one string of four 12-volt batteries wired in series)
12-volt
battery
(100 AH)
12-volt
battery
(100 AH)
overcurrent protection
to 48 VDC inverter
(total capacity = 100 Ahrs)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
overcurrent protection
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
to 48 VDC
inverter
(total capacity
= 400 Ahrs)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
6-volt
battery
(200 AH)
48-volt battery bank
(two strings of eight 6-volt batteries wired in series and paralleled)
12-volt
battery
(100 AH)
12-volt
battery
(100 AH)
12-volt
battery
(100 AH)
12-volt
battery
(100 AH)
12-volt
battery
(100 AH)
12-volt
battery
(100 AH)
48-volt battery bank
(two strings of four 12-volt batteries wired in series and paralleled)
12-volt
battery
(100 AH)
12-volt
battery
(100 AH)
to 48 VDC inverter (total
capacity = 200 Ahrs)
overcurrent protection
