4) Replace the oil seal.
Install the bearing,snap ring,and collar into the axle
housing,and then press in the oil seal by applying
force only to the circumference as shown in the
figure( Fig.7-11)
Apply force only to the shaded parts
Fig.7-11
Take care not to deform these portions
5) press in the wheel shaft.
6) Install the wheel gear and bearing on the
wheel shaft and retain them with nut.
7) Apply adhesive (THREE BOND 1215) to the
contact surfaces of the brake metal and housing
and then retain the plates by tightening the nuts
to the specified torque.
Fig.7-12
0.6-0.8 Kgf.m
(4.3-5.8ft-lbs)
Tightening torque
7-6

Mahindra 2810 Specifications

General

Engine Power	28 HP
Engine Cylinders	3
Drive	2WD
Engine Type	Diesel
Transmission	8 Forward + 2 Reverse
Steering Type	Manual
Clutch Type	Single
