1.2 INSPECTION
Before and after disassembly,inspect each part for points mentioned below,and replace if necessary.
9.5 Kgf
(20.9lbs)
13.0-18.8 Kgf
(28.7-41.5lbs)
Synchro-hub thrust for shifting
-51.17 ㎜
(2.015 in)
Assembled width of
synchromesh assembly
0.3 ㎜
(0.012 in)
0 ㎜(0 in)Stepped wear of teeth
0.5 ㎜
(0.020 in)
0.1 - 0.2 ㎜
(0.004-0.008 in)
Backlash of each gear (measured
in meshed condition)
Usable limitsStandard valuesInspection items
-Inspect bearings such as ball bearings and needle bearings for abnormalities in rotation such as
irregularity,hitching,etc.by turning them with pressure applied by hand.Replace defective ones.
-Seriously worn or damaged parts should also be placed.
5-7
