26
57 Remove the clutch.
58 Drain the oil from the oil pan.
59 Remove the nuts of the accelerator lever
bracket.
60 Remove the Accelerator lever bracket.
61 Remove the three bolts to remove the fuel
injection pump (13mm).
62 Remove the fuel injection pump & its
gasket.
63 Remove the camshaft.
Accelerator
Lever Bracket
Nut
Camshaft
Gear
Camshaft
Fuel Injection
Pump
Engine

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mahindra YUVRAJ 215 and is the answer not in the manual?

Mahindra YUVRAJ 215 Specifications

General IconGeneral
Engine Power15 HP
TransmissionSliding mesh
Number of Gears6 Forward + 3 Reverse
BrakesOil immersed brakes
PTO Power12 HP
Hydraulic Lifting Capacity500 kg
Number of Cylinders1
Rated Engine Speed2300 RPM
Wheel Base1490 mm
Weight780 kg
Engine TypeSingle Cylinder, Water Cooled
Fuel Tank Capacity19 Litres
SteeringMechanical
