Operating Instructions
27
Acoustic Reflex PDF or PC Printout
D
ata table:
Pressure = pressure compensation to match point of peak compliance from preceding
tympanometry measurement
Number of stimuli = number of test stimuli included in the protocol (up to four allowed)
Minimum for a pass = number of passing stimuli required to meet the compliance change
criteria
G
raphical table:
Each horizontal row shows the compliance changes for one stimulus type plotted as a function
of stimulus intensity which is indicated in the header for each vertical column.
The solid line shows the measured compliance change for a particular combination of stimulus
and intensity
Green = compliance change criteria has been met
Yellow = compliance change criteria has not been met
Red = the maximum intensity has been reached without meeting the compliance change criteria
Pass/refer is indicated at the end of each horizontal row
