14. FREQUENCY MEASUREMENT
1. Set the function switch to range
position. The meter automatically defaults to
Frequency range.
2. Press the button for 3 seconds to select
the Frequency range. The meter automatically
defaults to DC Volts.
3. Insert the red test lead into the “V Ω TEMP HZ”
input terminal and the black lead to the “COM”
terminal.
4. Connect the other end of the test leads to the
circuit or component under test. Take the
reading on the display.
Note: • In the Frequency range the meter is Auto
Ranging only.
Measuring Frequency
on AC Supply
Hz
13
V
__
~
__
__ __
Hz
MODE
