15. TEMPERATURE MEASUREMENT
1. Set the function switch to range position.
The meter automatically defaults to ºC range.
2. Insert the MT802 white temperature adaptor
into the “V Ω TEMP HZ” input terminal and the
“COM” terminal. Ensure that the “-” marking on
the adaptor is inserted into the “COM” terminal
and the “+” marking on the adaptor is inserted
into the “V Ω TEMP HZ” input terminal.
3. Connect any K-Type probe into the MT802
adaptor and measure the temperature of the
apparatus or area required.
4. Read the temperature directly on the display.
5. To change the measuring unit from ºC to ºF,
Press the button to select the ºF unit.
Note: • The meter is set to default to “Auto
Range” mode.
Temp
MODE
K-Type Adaptor
Ambient Temperature
K-Type
Wire Probe
14
