1: Introduction
This user guide explains how to set up and begin using the mangOH
®
Yellow with CF3 (Common Flexible Form
Factor) modules.
Once you have the mangOH Yellow set up, visit mangoh.io/mangoh-yellow-resources for developer
documentation, code samples, and other materials.
1.1 mangOH Yellow Components and Accessories
Table 1-1 details the required and optional components needed to begin using the mangOH Yellow in your
development environment. Some of these components are available in mangOH Yellow development kits (kit
contents are supplier-dependent).
Table 1-1: mangOH Yellow Required and Optional Components
Item Details Example
(1) mangOH Yellow with
integrated WP7702
CF3 module
Pre-configured development board for CF3 modules
The integrated (soldered-down) WP7702 module includes a
cellular modem and an application processor running Legato,
an open source embedded platform built on Linux for hosting
IoT applications (see legato.io for details).
(2) Micro-USB cables
(Included in kit)
Connects computer to the mangOH Yellow for communication
and to provide power for non-transmitting tests.
(1) Antenna, Ultra Wide
Band
(Included in kit)
Main RF antenna included.
IoT breakout board Breakout board for mangOH Yellow’s IoT connector
M2 screws
(Included in kit)
Two M2 screws included for IoT card installation
Audio cable (3.5 mm)
(Not included in kit)
Optional audio cable or headset
