3 - 27
E3 – FUEL TANK
CLEAN
Place the lift truck on level ground with the engine stopped.

IMPORTANT

While carrying out these operations, do not smoke or work near a flame.
Never try to carry out a weld or any other operation by yourself, this could provoke an explosion or a fire.
- Inspect the parts susceptible to leaks in the fuel circuit and in the tank both visually
and by touch.
- In the event of a leak, contact your dealer.
- Place a container under drain plug 1 and unscrew the plug.
- Open the fuel filler access panel with the ignition key.
- Remove filling plug 2 to ensure that the oil is drained properly.
- Rinse out with ten litres of clean diesel through filler port 3.
- Refit and tighten the drain plug (tightening torque 29 to 39 N.m).
- Fill the fuel tank with clean diesel filtered through the filler port.
- Refit the filler plug.
- If necessary, bleed the fuel supply system (see: 3 - MAINTENANCE: H1 - FUEL SYSTEM).
1
2
3
3
5
1
2
4
E4 – GEAR BOX OIL
DRAIN
E5 – GEAR BOX OIL FILTER
CHANGE
Place the lift truck on level ground with the engine stopped, the gear box oil still warm.

IMPORTANT

Raise the boom and place the boom safety wedge on the rod of the lifting cylinder
(see: 1 - OPERATING AND SAFETY INSTRUCTIONS: LIFT TRUCK MAINTENANCE INSTRUCTIONS).
Dispose of the drain oil in an ecological manner.
Tighten the oil filter by hand pressure only and lock the filter in place by a quarter turn.
DRAINING THE OIL
- Remove cover plate 1.
- Place a container under drain plug 2 and unscrew the plug.
- Remove dipstick 3 to ensure proper emptying.
REPLACEMENT OF THE FILTER
- Unscrew and discard gear box oil filter 4, together with its seal.
- Clean the filter bracket with a clean, lint-free cloth.
- Lightly grease the new seal before refitting the new oil filter (see: 3 - MAINTENANCE:
FILTERS, CARTRIDGES AND BELTS) on its bracket.
FILLING UP THE OIL
- Refit and tighten the drain plug 2 (tightening torque 34 to 54 N.m).
- Unscrew the filler cap 5, and fill up with oil (see: 3 - MAINTENANCE: LUBRICANTS
AND FUEL) through the port, and refit the filler cap 5.
- Start the engine and leave it at idle.
- Check for possible leaks from the drain plug
and the oil filter.
- Check the correct level against the MAX mark
on the dipstick 3.
- Top up the level if necessary.
- Refit cover plate 1.
647104 (13/06/2016) MT 835 / 1135 / 1335 ST3B
