Manitou MT 835 ST3B User Manual

2 - 12
CHARACTERISTICS MT 835 ST3B
I.C. ENGINE
Type
PERKINS 854E-E34TA JR51746
Fuel
Diesel
Number of cylinders
4 in line
Suction
Supercharged
Injection system
Direct
Ignition sequence 1.3.4.2
Capacity cm
3
3400
Bore and stroke mm 99 x 110
Compression ratio 17:1
Nominal speed laden rpm 2200
Idling speed slow unladen rpm 850
Max. speed unladen rpm 2350
Power ISO/TR 3046 cv - kW 102 - 75
Power SAE J 1995 cv - kW 102 - 75
Maximum torque ISO/TR 3046 Nm 420 to 1400 rpm
Gravimetric efficiency ISO 5011 % 99,9
Type of cooling By water
Fan Puller
TRANSMISSION
Gear box
DANA
- Type Mechanical
- Forward/reverse selector Electro-hydraulic
- Torque converter DANA
- Number of forward speeds 4
- Number of reverse speeds 4
Angle gear box -
Front axle DANA
- Differential Without locking
Rear axle DANA
- Differential Without locking
Drive wheels 4RM Permanent
- Switch for 2/4 drive wheels No
Front tyres
MICHELIN
- Size
400/80-24 156A8 POWER CL
- Pressure
bar
4
Rear tyres
MICHELIN
- Size
400/80-24 156A8 POWER CL
- Pressure
bar
4
ELECTRIC CIRCUIT
Battery
STANDARD
12 V - 110 Ah - 900 A EN
OPTION
12 V - 180 Ah - 1200 A EN
Alternator 12 V - 100 A
- Type ISKRA AAK-EF
Starter 12 V - 3,2 kW
- Type ISKRA AZE
BRAKE CIRCUIT
Service brake
Hydraulic power brake
- Type of brake Multidisk brake immersed in oil
- Type of control Foot-operated for the front and rear axles
Parking brake Low pressure brake
- Type of brake Disk on gear-box output
- Type of control Electro-hydraulic
SOUND AND VIBRATION
Sound pressure level in the driver's cab LpA
(according to standard NF EN 12053)
dB(A) 82 (cab closed) ; xx (cab open)
Sound pressure (according to directive2009/76) dB(A) xx (cab closed) ; xx (cab open)
Sound pressure level ensured in the LwA environment
(according to directive 2000/14/EC modified by directive 2005/88/EC)
dB(A) 105 (measured) ; 106 (ensured)
Sound level in motion (according to directive 2009/63) dB(A) xx
Average weighted acceleration on driver's body
(according to standard NF EN 13059)
m/s2 2
The average weighted acceleration transmitted to the driver's hand/
arm system (according to standard ISO 5349-2)
m/s2 < 2,5
Standard seat vibration m/s2 xx (lightweight operator) ; xx (heavyweight operator)
647104 (13/06/2016) MT 835 / 1135 / 1335 ST3B
