Manitou MT 835 ST3B User Manual

2 - 13
HYDRAULIC CIRCUIT
Hydraulic pump
- Type
Gear pump with flow divider on 2nd casing
1st casing 2nd casing
- Capacity cm3
31 22
- Max. rating capacity unladen l/mn
73 52
- Flow rate at 1600 rpm l/mn
50 35
Filtration
- Return μm
10 10
- Suction μm
135 135
Maximum service pressure bar
270
- Telescoping circuit bar
200 / 270
- Lifting circuit bar
280 / 280
- Tilt circuit bar
280 / 200
- Stabilizers Circuit bar
270
- Tilting corrector circuit bar
140
- Attachment circuit bar 270
- Steering circuit bar 140
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device
Electronic
Lifting motions (boom retracted)
- Unladen lifting s - m/mn
6,6 - 45,5
- Laden lifting s - m/mn
11,0 - 27,3
- Unladen lowering s - m/mn
6 - 50
- Laden lowering s - m/mn
5 - 60
Telescoping motions (boom raised)
- Unladen extending s - m/mn
6 - 29,8
- Laden extending s - m/mn
6 - 29,8
- Unladen retracting s - m/mn
5,6 - 31,9
- Laden retracting s - m/mn
5,2 - 34,3
Tilting movements
- Unladen digging s - °/s
3,2 - 39,4
- Forward tilting unladen s - °/s
3 - 42,1
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground
(except particular conditions)
Front unladen 1 km/h
5,1
2 km/h
8,1
3 km/h
15,2
4 km/h
25,7
Rear unladen 1 km/h
5,1
2 km/h
8,1
3 km/h
15,2
4 km/h
25,7
Standard attachment
TFF35 MT1040
- Weight with forks kg
160
- Weight of forks (each one) kg
70
Rated capacity with standard attachment kg
3500
Distance from the centre of gravity from the load to the lug of the forks mm
500
Standard lifting height mm
7750
Lift truck weight without attachment kg
6895
Lift truck weight with standard attachment
- Unladen kg
7195
- At rated load kg
10695
Weight per axle with standard attachment (transport position)
- Front unladen kg
3455
- Rear unladen kg
3740
- Front rated load kg
9535
- Rear rated load kg
1160
Weight per axle with standard attachment (boom extended)
- Front rated load kg
7725
- Rear rated load kg
620
Drag strain on the coupling hook
- Unladen (sliding) daN
6190
- At rated load (transmission setting) daN
8230
Pull strain with open carrier (according to standard ISO 8313) daN
6264
647104 (13/06/2016) MT 835 / 1135 / 1335 ST3B
