2 - 24
DIMENSIONS AND LOAD CHART
MT 1335 ST3B
A
mm
1200
B
mm
2880
C
mm
1798
C1
mm
1801
D
mm
5856
D1
mm
5859
D2
mm
4516
E
mm
7056
F
mm
1870
F1
mm
1870
G
mm
445
G1
mm
415
G2
mm
445
G3
mm
135
H
°
10
H1
°
10
I
mm
1178
J
mm
884
K
mm
1040
L
mm
45
N
mm
1740 - 1803
O
mm
125
P2
°
38
P3
°
31
R
mm
3643
S
mm
8097
T
mm
4084
U1
mm
2419
U2
mm
2559
V
mm
5224
V1
mm
1140
V2
mm
3850
W
mm
2284
W1
mm
2214
W2
mm
1267
W3
mm
2214
Y
°
12
Z
°
114
647104 (13/06/2016)
MT 835 / 1135 / 1335 ST3B
