4 - QUICK-RELEASE COUPLER ON ATTACHMENT CIRCUIT
6 - EXTERIOR DRAIN-BACK
Enables connection of an attachment for which drain-back is required.
• A - Fixed position, drain back not connected.
• B - Movable position, drain back connected.
5 - ANGULAR SECTOR ON BOOM
The angular sector displays the boom angle, and thus improves the reading of the load
charts.
3 - BOOM ELECTRICAL PREDISPOSITION
Enables an electrical function to be used at the head of the boom.
OPERATION
- Set switch 1 to position A to enable the predisposition, the indicator lights up to
show that it is enabled.
