12
R8 PRO SERVICE GUIDE
AIR SPRING SERVICE
9
Install air spring assembly into stanchion. Using a 22mm
Crows Foot OR 22mm deep-bore socket torque to 40-45
LB-IN [4.5-5.1 Nm]. If rod is bottomed, attach shock pump
to valve and draw the rod out until fully extended.
Liberally apply Slickoleum™ grease to the IVA piston seal
and outer piston surface. Apply Slickoleum™ grease to the
threads of the stanchion.
10
11
Insert IVA Piston into the stanchion.
To Next Page
