SET-UP AND INSTALLATION 31000 LUFFING JIB OPERATOR MANUAL
4-72 Published 07-23-15, Control # 078-03
2
Information below from drawing A19443, Sheet 28:
Boom up to allow the upper boom point (A) to hang vertically:
Step Action
FIGURE 4-78
Item Description
A Upper boom point.
B Drum 3 wire rope.
A
B
Boom up
Center of gravity
