UNDERCARRIAGE RT765E-2 SERVICE MANUAL
8-32
Published 9-04-2014, Control # 422-08
7683-2
FIGURE 8-29
4
6
12
15
5
1, 2, 3
1, 2, 3
9, 10
13, 14
13, 14
7, 8
11
16
20
12
17,18,19
Item Description
1 Retainer Pin
2 Cotter Pin
3Pin
4 Extend Port
5Retract Port
6 Outrigger Box
7 Side Wear Pad
8 Setscrew
9 Wear Pad
10 Setscrew
11 Extension Cylinder
12 Jack Cylinder
13 Cotter Pin
14 Clevis Pin
15 Pin
16 OMS Potentiometer
17 Capscrew
18 Lockwasher
19 Flatwasher
20 Spring Snap
Item Description
Reference Only
