Part Number Preliminary 6/11 185
SYMPTOM #4 SELF-CONTAINED AIR, WATER-COOLED OR REMOTE
Level Ice
Machine
Refer to
Dump Valve
Diagnostics
Is water flowing over the
evaporator in the first 45 seconds
of harvest?
Is Ice
Machine level?
Are back of the cubes
melted at end of
harvest cycle?
Does ice remain frozen to
the evaporator at the end of
the harvest cycle?
YES
YES
YES
YES
NO
NO
NO
NO
Ice Machine Will Not Harvest - Freeze Cycle is Normal and Ice Cubes are Melted After Harvest
Continued on Next Page...
Refer to
Symptom #2
Freeze Cycle
Operational
Analysis Table
To Next Page
