QUIETQUBE® MODELS- Freeze Cycle Refrigeration System Operational Analysis Tables
I Model QuietQube® Single Expansion Valve
Operational Analysis 1 2 3 4
Ice Production
Published 24 hour ice production________________
Calculated (actual) ice production_______________
NOTE: The ice machine is operating properly if the ice fill patterns is normal and ice
production is within 10% of charted capacity.
Installation and Water
System
All installation and water related problems must be corrected before proceeding with chart.
Ice Formation Pattern
Ice formation is
extremely thin on
outlet of evaporator
-or-
No ice formation on
the entire evaporator
Ice formation normal
-or-
Ice formation is
extremely thin on
outlet of evaporator
-or-
No ice formation on
entire evaporator
Ice formation normal
-or-
Ice formation is
extremely thin on
inlet of evaporator
-or-
No ice formation on
entire evaporator
Ice formation normal
-or-
No ice formation on
entire evaporator
