CALCULATING ALLOWABLE LINESET DISTANCE
Line Set Length
The maximum length is 100' (30.5 m).
Line Set Rise/Drop
The maximum rise is 35' (10.7 m).
The maximum drop is 15' (4.5 m).
35 ft. (10.7 m) Rise: The maximum distance the
Condenser or Condensing Unit can be above the ice
machine.
15 ft. (4.5 m) Drop: The maximum distance the
Condenser or Condensing Unit can be below the ice
machine.
SV1751
35 FT. (10.7 M)
MAXIMUM
DISTANCE
SV1750
15 FT. (4.5 M)
MAXIMUM
DISTANCE

Manitowoc Indigo Series Specifications

General

Model	Indigo Series
Ice Type	Nugget
Cooling System	Air-cooled, Water-cooled
Power Supply	Varies by model
Material	Stainless steel exterior
Water Connection	1/2" NPT water inlet
