Part Number Preliminary 6/11 33

Ice Machine Heat of Rejection

Series Ice

Machine

Heat of Rejection

Air

Conditioning*

Peak

I0300 4600 5450

I0320 3800 6000

I0450 5400 6300

I0500 6100 6900

I0520 5300 6100

I0600 9000 13900

I0850 13000 16000

I1000 16250 18600

I1200 20700 24500

I1400 23500 27000

I1800 30000 35000

I2100 31500 35500

I3300 40000 46000

*BTU/Hour

Because the heat of rejection varies during the ice making

cycle, the figure shown is an average.
