Remote Air-Cooled Condensing Unit Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24-HOUR ICE PRODUCTION
OPERATING PRESSURES
Freeze Time + Harvest Time = Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
8.7-10.0 10.8-12.4 12.3-14.1
.75-2.5
90/32 10.3-11.9 11.6-13.3 12.4-14.3
100/38 11.0-12.6 12.2-13.9 13.4-15.3
110/43 12.0-13.8 13.4-15.3 14.9-17.0
1
Times in minutes.
Air Temp.
Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
650 540 480
90/32 560 505 475
100/38 530 485 445
110/43 490 445 405
1
Based on average ice slab weight of 4.60 - 5.20 lb.
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
psig
Suction
Pressure
psig
Discharge
Pressure
psig
Suction
Pressure
psig
-20 to 50/
-29 to 10
200-250 44-26 180-210 65-85
70/21 235-255 50-28 185-210 65-90
80/27 245-275 50-28 190-210 75-100
90/32 250-290 52-30 195-215 75-105
100/38 270-320 52-31 210-240 80-110
110/43 300-360 60-32 215-260 85-115
