278 Part Number Preliminary 6/11

Self-Contained Charging Procedures

1. Be sure the ice machine is off.

Important

The charge is critical on all Manitowoc ice

machines. Use a scale to ensure the proper

charge is installed.

MANIFOLD SET

CLOSED

SCALE

VACUUM PUMP/

RECOVERY UNIT

OPEN

CLOSED

LOW SIDE

ACCESS

VALVE

HIGH SIDE

ACCESS

VALVE

OPEN

REFRIGERANT

CYLINDER

CHARGING CONNECTIONS
