Manitowoc Indigo Series User Manual

302 Part Number Preliminary 6/11
QuietQube® ICVD Models
NOTE: All ice machines on this list are charged using R-404A
refrigerant.This information is for reference only. Refer to the ice
machine serial number tag to verify the system charge. Serial plate
information overrides information listed on this page.
Model
Condensing
Unit
Refrigerant
Charge
Line Set
Length
I0680C I0680C
IB0690C
ICVD0695
11 lbs.
5 kg.
0-100 ft.
0-30 M
I0870C ICVD0895
11 lbs.
5 kg.
0-50 ft.
0-15 M
12 lbs.
5.44 kg
51-100 ft.
15-30 M
IB0890C ICVD0895
11 lbs.
5 kg
0-100 ft.
0-30 M
I1070C ICVD1095
10 lbs.
4.5 kg
0-50 ft.
0-15 M
11 lbs
5 kg
51-100 ft.
15-30 M
IB1090C ICVD1195
12 lbs.
5.44 kg
0-100 ft.
0-30 M

Manitowoc Indigo Series Specifications

General

Model	Indigo Series
Ice Type	Nugget
Cooling System	Air-cooled, Water-cooled
Power Supply	Varies by model
Material	Stainless steel exterior
Water Connection	1/2" NPT water inlet
