Part Number Preliminary 6/11 69

NOTE: During cleaning, do not stretch or damage the

spring.

1. Remove the tubing from the dump valve by

twisting the clamps off.

2. Remove the valve body, twist off.

Dump Valve Disassembly

SPRING

PLUNGER

DIAPHRAM

VALVE BODY

COIL

MOUNTING BRACKET

NYLON GASKET
