NATIONAL CRANE Published 11-01-2020 Control # 710-00 5-15
NBT60XL OPERATOR MANUAL LUBRICATION PROCEDURE AND CHARTS
Item Description
1 Counterweight Pins
2 Hoist Plumbing Connections
3 Tension Spring
4 Pivot Shaft
5 Valve bank, Hose Connections inside turntable
6 Wire Rope
7 Boom Nose Pins, Clips
8
All Hardware, Clips, Pins, Hose Connections
not painted Outrigger Pins, Clips
9 Downhaul Weight/Hook block
10 Downhaul Weight/Hook Block Tiedown
11 Mirror Mounting Hardware
12 Powertrain Hardware
13 Outrigger Hose Connections
14 Outrigger Pins, Clips
15 Entire underside of unit
16 Turntable Bearing Fasteners
17 Outrigger Beam Hardware
18 Boom Extension Hardware (Optional)
