CONTROLS AND OPERATING PROCEDURES OPERATOR MANUAL NBT60XL
3-10 Published 11-01-2020 Control # 710-00
CRANE CONTROLS
2
3
23
20
19
18
16
17
15
22
21
10258
9598
40
5
9
10
12
1
6
14
42
11
45
44
48
43
13
46
9596
9597
FIGURE 3-4
4
Item Description
1 Outrigger Control Panel
2 Swing Brake Pedal
3 Boom Telescope Pedal (Optional)
4 Foot Throttle Pedal
5 Display Panel Assembly
6 RCL Bypass Switch
7 Swing Brake Indicator
8 Minimum Indicator
9 Emergency Stop Switch
10 A/C Heater Vent
11 Ignition Switch
12 Receptacle (12v)
13 Display Diagnostic Connector
14 Crane Level Indicator
15 Truck Engine Hi/Low Switch
16 Crane Function Power Switch
17 Remote Power Switch (Optional)
18 Work Light Switch
19 Skylight Wiper Switch
20 Windshield Wiper Switch
21 A/C Heater Function Switch
22 A/C Heater Temperature Control
23 A/C Heater Fan Speed
24 Radio (AM/FM, USB, Bluetooth)
Item Description
24
47
Fo
r
Reference
Only
