68 Part Number 80-1505-3 6/11
S1470C/S1870C/S2070C/S2170C
AIR
PUMP
DISTRIBUTION
TUBE
ICE
THICKNESS
PROBE
EVAPORATOR
SPLASH
SHIELD
BIN
SWITCH
WATER
TROUGH
SHIELD
ICE
DAMPER
WATER
TROUGH
WATER
PUMP
DUMP
VALVE
RECEIVER
LIQUID LINE
SOLENOID
VALVE
DRIER
ICE/OFF/
CLEAN
SWITCH
WATER
LEVEL
PROBE
LEFT SIDE
HARVEST
VALVE
TXV SENSING
BULB
BOOT
AIR
PUMP
EXPANSION
VALVE
WATER
INLET
VALVE
