92 Part Number 80-1505-3 6/11
E. Remove the water trough
• Remove the quarter turn fasteners (turn
counterclockwise) securing the trough in place.
• Pull forward on the water trough until the rear pins
disengage from the water trough.
• Lift up and forward on the front of the water trough
while allowing the rear of the water trough to drop.
• Remove the water trough from the ice machine.
F. Remove the water distribution tube
• Remove the clamp from the vinyl water hose on
the right side of the distribution tube.
• Loosen the two thumbscrews which secure the
distribution tube.
• Lift the right side of the distribution tube up, and
then rotate it backward and to the right until the left
side of the distribution tube disengages the
thumbscrew.
• Pull the vinyl hose off the distribution tube.
Disassemble for cleaning:
• Twist both of the inner tube ends until the tabs line
up with the keyways.
• Pull the inner tube ends outward.
