GROVE Published 1-20-2017, Control# 483-02 7-23
CD5515-2/YB5515-2 SERVICE MANUAL TRANSMISSION AND TORQUE CONVERTER
page 7-1. A high or low reading could indicate a faulty
converter relief valve.
3. Remove the pressure test gauge.
Converter Relief (Safety) Valve Pressure
1. Connect a 0-20 bar (0-300 psi) pressure gauge to test
point B Figure 7-15.
2. Install a load valve P into the converter out line.
NOTE: Make sure the load valve is in the OPEN position
(the adjusting knob screwed fully out) before
starting the following pressure test. If the load valve
is not fully open, damage to the converter seals will
occur.
3. Start the engine and run at 1000 rpm. With the
transmission in neutral, slowly screw down the load
valve P while observing the gauge reading which should
rise to the converter relief valve setting specified on
page 7-1.
4. If the reading is higher than specified the converter relief
valve is faulty. A low reading indicates a leaking pump
seal or faulty converter relief valve.
5. Stop the engine and remove the test gauges and install
hoses to original position.
Lubricating Pressure
1. Stop the engine and connect a suitable pressure gauge
into the return line from the oil cooler to the transmission
as shown in J Figure 7-15.
2. Start the engine and run at 1000 rpm. With the
transmission in neutral, the pressure gauge will indicate
the lubricating pressure. Compare the pressure reading
with the specification on page 7-1.
3. Repeat step 2 and note the pressure with the engine
running at 2000 rpm.
4. Stop the engine and remove the pressure gauge.
CAUTION
DO NOT allow the pressure to exceed 10.34 bar (150 psi)
or damage to the converter seals will occur.
Reference Only
