GROVE Published 1-20-2017, Control# 483-02 3-9
CD5515-2/YB5515-2 SERVICE MANUAL ELECTRIC SYSTEM
3
FIGURE 3-4
Tier 3 Engine Wire Harness
Alternator
Coolant
Sensor
ECM
Ground
To
Carrier
WIF Connector
on Fuel Filter
AC
Compressor
Engine ECM
Connector
Engine Power
Connector
WIF Connector
on Engine
J1939 Terminating
Resistor
Engine Ground
Foot Pedal
Connectors
Reference Only
