ELECTRIC SYSTEM CD5515-2/YB5515-2 SERVICE MANUAL
3-10 Published 1-20-2017, Control# 483-02
FIGURE 3-5
Tier 4 Engine Wire Harness
Alternator
Coolant
Sensor
ECM
Ground
To
Carrier
WIF Connector
on Fuel Filter
AC
Compressor
Engine ECM
Connector
J1939
Terminating
Resistor
Engine Ground
Foot Pedal
Connectors
MAF Sensor
Air Cleaner
OEM Breakout
Connector
ECM MAF
Sensor
WIF Sensor
Engine
Reference Only
