122 Part Number: 040006847 12/19
Tubing Schematics
UG0020A
1
5
6
7
2
4
3
9
8
Number Component
1 Compressor
2 Harvest Solenoid
3 Condenser
4 Receiver - Water-Cooled Only
5 Liquid Line Drier
6 Heat Exchanger
7 Heat Exchanger
8 Capillary Tube
9 Evaporator
