Part Number: 040006847 12/19 23
Leveling the Ice Machine
1. Screw the legs or levelers into the bottom plate of the
ice machine.
2. Screw the foot of each leg or leveler in as far as
possible. Move the ice machine into its final position.
3. Use a level on top of the ice machine. Turn each foot
as necessary to level the ice machine from front to
back and side to side.
Cooling of the Ice Machine
Ice Machine
Model
Cooling
Air conditioning* Peak
UG0020 1400 2600
UG0030 1900 3300
UG0040 2100 4100
UG0050 2600 5000
UG0065 2900 5000
UG0080 4300 7400
*BTU/Hour
The amount of heat dissipated varies during the ice making cycle.
The listed values are average values.
