Part Number: 040006847 12/19 67
Electrical Components
ON/OFF/WASH TOGGLE SWITCH
Function
The switch is used to place the ice machine in ON, OFF or
WASH mode of operation.
Specifications
Double-pole, double-throw switch.
Check Procedure
1. Inspect the toggle switch for correct wiring.
2. Isolate the toggle switch by disconnecting all wires
from the switch.
3. Check across the toggle switch terminals using a
calibrated ohmmeter. Note where the wire numbers
are connected to the switch terminals, or refer to the
wiring diagram to take proper readings.
Switch Setting Terminals Ohm Reading
ON
5-6 Open
5-4 Closed
2-1 Closed
2-3 Open
WASH
5-4 Open
5-6 Closed
2-3 Closed
2-1 Open
OFF
2-3 Open
2-1 Open
5-6 Open
5-4 Open
Replace the toggle switch if ohm readings do not match all
three-switch settings.
Component Check Procedures
