48 Part Number: 040006847 12/19
SUMP DRAIN OVERFLOW TUBE
The sump drain overflow tube is located in the evaporator
water sump:
1. Remove the water curtain and ice chute.
2. Lift spray bar or disconnect and remove for easiest
access.
3. Pull up on the overflow tube to remove.
4. To replace plug, insert in hole, and push with force to
make a tight seal.
Overflow Tube
